Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface

Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface

  • High Light

    galvanized light pole

    ,

    highway light pole

  • Surface Treatment
    Hot Dip Galvanized And Powder Coated
  • Material
    Q235B Or Q345B Or Others
  • Height
    Custom
  • Wall Thickness
    3-20mm
  • Pole Shape
    Octagonal
  • Welding Standard
    AWS D 1.1
  • Painting Color
    According To The RAL Color Number From Clients
  • Package
    Blanket Or Plastic Woven Bag
  • Palce Of Origin
    Jiangsu China
  • Certificate
    SGS And ISO
  • Place of Origin
    CHINA
  • Brand Name
    Futao
  • Certification
    FUTAO
  • Model Number
    LP-027
  • Minimum Order Quantity
    2
  • Price
    USD100-USD600
  • Packaging Details
    old blanket or plastic woven bag
  • Delivery Time
    30 - 60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    6000 pcs every month

Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface

                                   Outdoor Galvanized 3~30m Street Light Pole Q235 Street Lighting Pole Lamp Post Pole

  • Products are designed and manufactured according to the wind speed client provided
  • Products are hot dip galvanized according to ISO 1461/ASTM A123 or Bristish standards
  • Average galvanization thickness in bulk is about 85um.
  • Pole shaft material : Q235B or Q345B
  • Welding standard:AWS D 1.1
  • We possess the ISO 9001:2015 certification and are committed to giving our customers the best products and service
  • We provide additional assistance if required including supervision and supplementary components
  • We custom the poles according to our customers’ specifications

Product Specifications



Height From 3 m to 30m
Apply in Highway, freeway, Airport ,seaport,plaza,stadium,square,highway,street way etc
Shape Conical, octagonal, square, cylinder
Material Usually Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52
Lamp power

20 W- 400 W (HPS/MH)

220

Tolerance ± 2%
Optical assembly of lighting fixture IP 65
Electroshock resistant protective grade Grade one
The casing anti-corrosion performance Class two
Working atmosphere of lighting fixture -35 °C~+45 °C
Surface treatment Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles Insert mode,inner flange mode,face to face joint mode
Design of pole Against earthquake of 8 grade
Wind Speed 160 Km/Hour
Minimum ultimate tensile strength 490 mpa
Max ultimate tensile strength
620 mpa
Standard ISO 9001
Length of per section Within 12m once forming without slip joint
Welding

We has past flaw testing.Internal and external double welding makes the welding beautiful in shape

Welding Standard :AWS ( American Welding Society ) D 1.1



Packaging & Shipping




We pack the top and bottom parts of the pole with an old blanket in order to protect it from damage to the galvanized surface that may occur during transportation.

Packaging can also be done according to clients’ requirements,such as plastic bubbles or with wooden stick between each layer.



Process of Production


Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration→ Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging

Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface 0

Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface 1Outdoor Street Light Pole Q235 Hot Dip Galvanized / Powder Coated Surface 2





Our Service


1. Reply your inquiry in 12 working hours.
2. Experienced staffs answer all your questions in fluent English quickly.
3. We have professional engineers to design the poles for clients.UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory: We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.
7. Sample time: about 10 workdays after receiving the sample fees.


Welcome to our factory!
