Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms

Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms

  • High Light

    highway light pole

    ,

    octagonal light pole

  • Material
    Q235B Or Q345B Or Q275 Or Others
  • Height
    Custom According To The Client's Request
  • Plate Thickness
    3-20mm
  • Pole's Shape
    Octagonal,round,conical Or Others
  • Welding Standard
    AWS D 1.1
  • Surface Treatment
    Hot Dip Galvanized
  • Painting Color
    According To The RAL Color Number From Clients
  • Package
    Blanket Or Plastic Woven Bag Or Others
  • Place Of Origin
    Jiangsu China
  • Certificate
    SGS And ISO
  • Place of Origin
    CHINA
  • Brand Name
    FUTAO
  • Certification
    FUTAO
  • Model Number
    LP-025
  • Minimum Order Quantity
    2
  • Price
    USD100-USD600
  • Packaging Details
    old blanket or plastic woven bag
  • Delivery Time
    30 - 60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    6000 pcs every month

Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms

Product Description



Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms



  • Products are designed and manufactured according to the wind speed client provided
  • Products are hot dip galvanized according to ISO 1461/ASTM A123 or Bristish standards
  • Average galvanization thickness in bulk is about 85um.
  • Pole shaft material : Q235B or Q345B
  • Welding standard:AWS D 1.1
  • We possess the ISO 9001:2015 certification and are committed to giving our customers the best products and service
  • We provide additional assistance if required including supervision and supplementary components
  • We custom the poles according to our customers’ specifications

To design in accordance with PLS software, we will require the following design parameters:


  1. The operational wind speed of the region where the pole will be used
  2. The weight of light and height of the pole
  3. The total height of the pole itself

Product Specifications


Type

Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms

Suitable Uses Street roads
Shape( Cross section)

Octagonal

Arm length 1.5m-3m
Arm type straight,bending or others
Length (m) 8M
Foundation M24*750mm,nuts,washers
Material Q235B or Q345B or others
Thickness 3-10mm
Top Diameter A/F60mm
Bottom Diameter A/F156mm
Tolerance of Dimensions +- 1%
Surface Treatment

Hot Dip Galvanization according to ASTM A123 standards or Bristish Standards.

The averge galvanization thickness in bulk is about over 85um

Powder Coating according to the RAL color number from clients



Package

old blanket or plastic woven bag



Welding

Welding Standard :AWS D 1.1



Packaging & Shipping




We pack the top and bottom parts of the pole with an old blanket in order to protect it from damage to the galvanized surface that may occur during transportation.

Packaging can also be done according to clients’ requirements,such as plastic bubbles or with wooden stick between each layer.







Process of Production


Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration→ Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging

Galvanized Solar Street Light Pole/Steel Light Pole/Lamp Post With Single Or Double Arms 0





Our Service


1. Reply your inquiry in 12 working hours.

2. Experienced staffs answer all your questions in fluent English quickly.

3. We have professional engineers to design the poles for clients.UEM&UBM are welcomed.

4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.

5. Special discount and protection of sales are provided to our distributor.

6. Professional factory: We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.

7. Sample time: about 10 workdays after receiving the sample fees.
