Hot Dip Galvanized Steel Utility Pole 35FT 40FT 10.5m 12m For Power Distribution

Hot Dip Galvanized Steel Utility Pole 35FT 40FT 10.5m 12m For Power Distribution

  • Highlight

    steel transmission pole

    ,

    steel power poles

  • Surface Treatment
    Hot Dip Galvanized
  • Powder Coated
    White, Blue, Sliver, Grey Or More
  • Material
    Hot Roll Steel Q345B, GR65
  • Height
    15m - 30m
  • Thickness
    7mm -16mm
  • Wind Resistance
    160 Km/h
  • Shape
    Round Or Polygonal
  • Place of Origin
    CHINA
  • Brand Name
    Futao
  • Certification
    ISO 9001
  • Model Number
    EP031
  • Minimum Order Quantity
    2 Pieces
  • Price
    $300 - $3,999.00/ Piece
  • Packaging Details
    40HC or OT, wrap by mat or straw mat
  • Delivery Time
    30-60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1200 pieces every month

Hot Dip Galvanized Steel Utility Pole 35FT 40FT 10.5m 12m For Power Distribution

                                               35ft, 40ft, 10.5m ,12m steel pole Hot Dip Galvanized Steel Utility Pole



Product Description


The products above are steel utility poles made specifically for power distribution between 10KV to 550KV.

  • At Futao Metal, we know your power delivey structure needs may require more than one type of pole. To fulfill your every needs, we can provide a multitiude of different pole types such as suspension, angled and dead end poles. We are fully commited to give you the best experience possible.

SERVICES 1.11.1 Contractor's Living Accommodation The Contractor shall make his own arrangements with regard to accommodation for his staff or workforce, either foreign or locally-recruited, during the construction of the lines. 1.11.2 Site Office The Contractor shall provide an office for DES site staff during the erection of the Works. The office shall be furnished with a telephone, a facsimile machine, multi-media micro-computers (2 nos.) with e-mail and internet facilities, high-quality printers (1xcolour & 1xblack/white), a scanner, an overhead projector, and a photocopier machine for the use of DES and the Contractor's site staff. TWO (2) rooms are to be reserved solely for the use of DES site staff which shall be furnished with two (2) sets of tables and chairs, two (2) nos. of file cabinets and be air-conditioned. The cost for the provision of the site office and related facilities (as mentioned above) shall be deemed included in the Contract Price. 1.11.3 Storage Facilities The Contractor shall in all cases make his own arrangements, at his own expense, with related landowners for suitable storage areas and camp sites, both within and outside the rentis. Detail requirements for the site store shall be as per Clause 1.35. 1.12 CONSTRUCTION UTILITIES All construction utilities required for the site staff (including the site office) and undertaking of the works shall be provided and be the responsibility of the Contractor



Customer: NAFTEX
BUYER. EDESUR
Design Load   Safety Factor 2
%Load Load(kg) Act.Load(kg) Time(min.) Deflection(mm) Recovery
(mm)
Remarks
100% 300 303 1 275 3 Passed
No signed of failure or damage at design load
120% 360 364 1 330 3
140% 420 426 1 392 4
160% 480 481 1 446 4
180% 540 549 1 511 4
200% 600 602 5 560 5
breaken   808
Witnesses:



Q1. How can I get a price of needed pole?

A: 1. Please provide exact dimensions such as height, pole shaft material type and thickness, top and bottom diameters. We can then give you an accurate quotation based on your specifications.

2. You can send us a detail and assembly drawing; we can then provide you with an accurate quotation based on the drawing.

Q2. I am a small wholesaler; do you accept a small order?
A: It's not a problem if you are a small wholesaler; we accept orders of various quantities.
Q3. I am a designer; Can you help me to produce the sample which we designed?
A: Our mission is to help our customers be successful. We are more than happy to help you solve any problems that you may have.
Q4. We want be your agent for our area. How do I apply for this?
A: Please send your proposal and your company profile to
Q5. Tell me about your company?
A : We have been a manufacturer and exporter of all kinds of steel poles including power poles, street lighting poles, telecommunications poles and other steel based products since 2000. Our products have been exported to many regions around the world.
Q6. Do you have some special policies for Branded companies?
A: Yes, we have some special support for the company who has own brand but are also in our VIP customers list. Please send us a copy of your sales data so we can analyze the best course of action in supporting you for your products in your market.
Q7. Do you provide Door to Door service? Because i don't know how to deal with customs clearance.
A: Yes. We provide Door to Door service to help you reduce shipping time and costs. This is because we have additional discounts with the shipping companies as we have done many shipments in the past. This in turn will save you lots of time and money.
