30FT 9m / 25FT 7.6m Metal Utility Pole Custom Powder Coated 7mm -16mm Thickness

30FT 9m / 25FT 7.6m Metal Utility Pole Custom Powder Coated 7mm -16mm Thickness

  • High Light

    electric utility pole


    steel transmission pole

  • Surface Treatment
    Hot Dip Galvanized
  • Height
    15m - 30m
  • Material
    Hot Roll Steel Q345B, GR65
  • Thickness
    7mm -16mm
  • Powder Coated
    White, Blue, Sliver, Grey Or More
  • Wind Resistance
    160 Km/h
  • Shape
    Round Or Polygonal
  • Place of Origin
  • Brand Name
  • Certification
    ISO 9001
  • Model Number
  • Minimum Order Quantity
    2 Pieces
  • Price
    $300 - $3,999.00/ Piece
  • Packaging Details
    40HC or OT, wrap by mat or straw mat
  • Delivery Time
    30-60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1200 pieces every month

30FT 9m / 25FT 7.6m Metal Utility Pole Custom Powder Coated 7mm -16mm Thickness

                                           30ft 9m ,25ft ,7.6m Steel Utility Pole, metal utility poles


Product Description

The products above are steel utility poles made specifically for power distribution between 10KV to 550KV.

  • Products are designed and manufactured according to ANSI/TIA-222-G structural standards
  • Only our company can comply to these global manufacturing standards which gives us an edge over our competitors
  • Products are hot dip galvanized according to ISO 1461/ASTM A123 standards
  • Pole shaft material : ASTM GR65,GR50,Q460 A572,S355,Q345/Q235,etc
  • Material code : GB/T1591-2008,GB/T700-2006
  • We possess the ISO 9001:2015 certification and are committed to giving our customers the best products and service
  • We provide additional assistance if required including supervision and supplementary components
  • We accommodate various designs according to our customers’ specifications

Receipt inspection All materials or equipment purchased under the Contract may be inspected at the specified receiving points, and be accepted or rejected there and then by DES. Inspection will include the necessary testing for determining compliance with the Specifications. All expenses of initial acceptance tests shall be included in the Contract. The expenses of any subsequent tests due to failure of materials or equipment first offered will be charged against the Contractor.


Type Steel Tubular Utility Pole for Power Distribution
Suitable Uses Power Distribution

Tubular, Polygonal or Conical


Q345B/A572,minimum yield strength>=345n/mm2

Q235B/A36,minimum yield strength>=235n/mm2

Other materials may be used as per request (Q460 ,ASTM573 GR65, GR50, SS400, SS490, to ST52)

Tolerance of Dimensions +- 1%
Power 10 KV ~550 KV
Safety Factor

Safety factor for conducting wire : 8

Safety factor for grounding wire : 8

Design Load in Kg 300~ 1000 Kg applied to 50cm from pole top
Engraving Name plate through rivet or glue ,engraving ,embossment as per customers’ requirements
Surface Treatment

Hot Dip Galvanization according to ASTM A123 standards/Powder Coating

Joint of Poles

Insert Mode, Inner Flange Mode, Face to Face Joint Mode.

Design of pole Against earthquake of 8 grade
Wind Speed 160Km/Hour 30m/s
Minimum Yield Strength 355 mpa
Minimum Ultimate Tensile Strength 490 mpa
Max Ultimate Tensile Strength 620 mpa
Standard ISO 9001
Length per section Within 14m once formed without slip joint

Internal and external double welding process produces a seamless surface

Welding Standard :AWS ( American Welding Society ) D 1.1

Thickness 2 mm to 30 mm
Production Process Verification of Materials→Cutting→Molding or Bending→Vertical Welding→Verification of Dimensions→Flange Welding→Hole Drilling→Calibration→Deburr Process→Galvanization or Powder Coating, Painting→Recalibration→Threading→Packaging
Packaging Our poles are usually covered by a mat or straw bale at the top and bottom. Packaging can also be done according to clients’ requirements.
