Q235B Galvanized Steel Cctv Camera Pole / Steel Pole/ Camera Pole
Specification for customized lamp pole:
Flange: According to the size of lamp pole ( Supply together)
Lamp pole shape: Round, Octangular, hexagon, square, frame, polygon or customized
Underground Cage: optical
Kindly remind:
Considering the volume of the undergrond cage is big, and simple processing, usually we suggest our customer to
make it at local area which can save them much shipping cost.
Drawing page of underground cage can supply
Pole Body: round structure, hot galvanizing, no rusted in 20 years (spray painting and colors are optional)
Specification Details
| Item | Traffic Camera Monitor Pole CCTV Camera Pole Monitoring Cctv Pole |
| Material | Steel(Q235,Q345,GR50,GR65 or others) |
| Mounting Height | 6m,9m,10m and so on |
| Pole Shape | Conical, Polygonal, Round |
| Welding Standard | AWS D 1.1 |
| Base Plate Mounting | Round or Square based plate |
| Ground Mounting | The bottom part of the pole shall be buried underground at site. Depth of burial as per clients’ requirements |
| Galvanization | Hot Dip Galvanization and average thickness of galvanization 85µm in bulk |
| Powder Coating | Pure Polyester Powder Painting, RAL color number according to the client's request. |
| Package | Plastic Woven Bag or Old Blanket or others |
| Anchor bolts,washers,nuts | included |
Process of Production
Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration → Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging
Product Details
Testing
Packaging & Shipping
We pack the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may occur during transportation.
Packaging can also be done according to clients’ requirements.
We can ship the poles by sea or air or express or trains and we have our regular shipping agent.
