Polygonal Shape CCTV Camera Pole  Hot Dip Galvanized CCTV Posts With Painting

Polygonal Shape CCTV Camera Pole Hot Dip Galvanized CCTV Posts With Painting

  • High Light

    surveillance camera pole

    ,

    security camera pole

  • Material
    Steel Pipe
  • Type
    Polygonal Shape
  • Appearance Treatment
    Hot-dip Galvanized
  • Arm Type
    Rectangle Or Others
  • Origin
    Jiangsu China
  • Certificate
    ISO9001:2008
  • Place of Origin
    China
  • Brand Name
    Futao
  • Certification
    ISO 9001
  • Model Number
    FT-CP036
  • Minimum Order Quantity
    2 Pieces
  • Price
    $80 - $1000
  • Packaging Details
    40HC or OT, wrap by mat or straw mat
  • Delivery Time
    30 - 60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1200 pieces every month

Polygonal Shape CCTV Camera Pole Hot Dip Galvanized CCTV Posts With Painting

                                     High Quality Hot Dip Galvanized CCTV Camera Pole With Painting





Product Description



Pole’s height 5m to 15m



Shape of pole

Round conical; Octagonal tapered; Straight square; Tubular stepped;

Shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine

Brackets/ Arm Single or double brackets/ arm are in the shape and dimension as per customers requirement
Length Within 14m once forming without slip joint
Wall thickness 2.5mm to 20mm
Welding It has past flaw testing.Internal and external double welding makes the welding beautiful in shape.And confirms with international welding standard of CWB
Jointing Jointing of pole with insert mode,innerflange mode,face to face joint mode.
Base plate mounted Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement.
Ground mounted The length buried underground as per customers requirement.
Galvanizing

Hot dip galvanization with thickness of 80-100µm average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS: 2626-1985.



Powder coating

Pure polyester powder painting, color is optional according to

RAL Color stardand.

Wind Resistance Aganist wind pressure of 160Km/h
Manufacturing According to GB/T 1591-1994.
Quality Control We control the quality according to the flow of ISO9001-2008. Quality is employed at every stage of production to ensure the product compliance to the specifications/standards. Careful inspections are carried out by highly trained inspection engineers as per the defined procedures from raw material stage to finished product and delivery. Prototype assembly of towers is carried out in the plant.



Process of Production


Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration → Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging

Polygonal Shape CCTV Camera Pole  Hot Dip Galvanized CCTV Posts With Painting 0

Packaging & Shipping


We pack the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may occur during transportation.

Packaging can also be done according to clients’ requirements.

We can ship the poles by sea or air or express or trains and we have our regular shipping agent.



FAQ



Trade terms:

1. Price Term: EXW,FOB,CFR,CIF,FCA or others.

2. Payment: 30%T/T in advance,70%T/T or L/C at sight before shipment. Other payment way can be negotiated.

3. Package: Plastic woven bag or old blanket or according to clients requirement.

4. Delivery time: within 30-60 workdays after receiving deposit.





Q1. How can I get a price of needed pole?

A: 1. Please provide exact dimensions such as height, pole shaft material type and thickness, top and bottom diameters. We can then give you an accurate quotation based on your specifications.
2. You can send us a detail and assembly drawing; we can then provide you with an accurate quotation based on the drawing.

Q2. I am a small wholesaler; do you accept a small order?
A: It's not a problem if you are a small wholesaler; we accept orders of various quantities.
Q3. I am a designer; Can you help me to produce the sample which we designed?
A: Our mission is to help our customers be successful. We are more than happy to help you solve any problems that you may have.
Q4: We want be your agent for our area. How do I apply for this?
A: Please send your proposal and your company profile.It will be better if we can know the estimated purchase quantity of every year.
Q5. Tell me about your company?
We have been a manufacturer and exporter of all kinds of steel poles including power poles, street lighting poles, telecommunications poles and other steel based products since 2000. Our products have been exported to many regions around the world.
Q6. Do you have some special policies for Branded companies?
A: Yes, we have some special support for the company who has own brand but are also in our VIP customers list. Please send us a copy of your sales data so we can analyze the best course of action in supporting you for your products in your market.
Q7. Do you provide Door to Door service? Because i don't know how to deal with customs clearance.
A: We provide Door to Door service to help you reduce shipping time and costs. This is because we have additional discounts with the shipping companies as we have done many shipments in the past. This in turn will save you lots of time and money.
Q8. Could you please recommand some poles to us? Because I don't know how to choose a pole.
A:   Yes,we can recommand some styles according to your target price or other information.
