132kv 138kv 32m 60-90degree Self support Steel pole ,Galvanised power pole
Product Description
The products above are 132kv 138kv 32m 60-90degree self support steel pole ,galvanised power pole
To design in accordance with PLS software, we will require the following design parameters:
Product Specifications
132kv Galvanized steel pole for karachi Electric Supply Company Karachi,Pakistan.
& need of following type of poles for 132 kv & 220 kv lines;
The specification reference the following standards
| ASCE/SEI 48: | Design of steel transmission pole structures |
| BS EN ISO 1461 : | Hot dip galvanized coatings on fabricate d iron and steel articles. Specification and test methods. |
| ASTM A123 : | Standard specification for zinc (hot galvanized) coating on Iron and Steel Products |
| ASTM A 153/A153M : | Standard specification for zinc (hot galvanized) coatings on iron and steel Hardware |
Design as follows:
| Section-I | Section-II | Section-III | Section- IV | X-arms | |
| Light angle pole | 1290x14x976 | 1052x14x759 | 821x12x528 | 573x8x280 | 280x8 x130 |
| Medium angle pole | 1560x14x1228 | 1321x14x941 | 1011x12x631 | 680x10x300 | 200x8x430 |
| Heavy angle pole | 1490x18x1115 | 1212x16x881 | 959x12x626 | 681x10x350 | 130x8280 |
Matercial grade .
| (2).The mechanics capability of Allow alloy high intension steel | |||||||||||||
| Steel grade |
Grade | Thickness(dia,length)mm | T.S δb(Mpa) |
P.E. | Test temperature(C) | 180º Bend test | |||||||
| <=16 | >16-35 | >35-50 | >50-100 | δb | +20 | 0 | -20 | -40 | [d=bend dia,a=Th(dia)] | ||||
| Y.S δb(Mpa)>= | >=% | IMPACT TEST(J) Akv(vertical) | Thickness(dia)mm | ||||||||||
| (J)>= | <=16 | >16-100 | |||||||||||
| Q295 | A | 295 | 275 | 255 | 235 | 390-570 | 23 | --- | --- | --- | --- | d=2a | d=3a |
| B | 295 | 275 | 255 | 235 | 390-570 | 23 | 34 | --- | --- | --- | d=2a | d=3a | |
| Q345 | A | 345 | 325 | 295 | 275 | 470-630 | 21 | --- | --- | --- | --- | d=2a | d=3a |
| B | 345 | 325 | 295 | 275 | 470-630 | 21 | 34 | --- | --- | --- | d=2a | d=3a | |
| C | 345 | 325 | 295 | 275 | 470-630 | 22 | --- | 34 | --- | --- | d=2a | d=3a | |
| D | 345 | 325 | 295 | 275 | 470-630 | 22 | --- | --- | 34 | --- | d=2a | d=3a | |
| E | 345 | 325 | 295 | 275 | 470-630 | 22 | --- | --- | --- | 27 | d=2a | d=3a | |
| Q395 | A | 390 | 370 | 350 | 330 | 490-650 | 19 | --- | --- | --- | --- | d=2a | d=3a |
| B | 390 | 370 | 350 | 330 | 490-650 | 19 | 34 | --- | --- | --- | d=2a | d=3a | |
| C | 390 | 370 | 350 | 330 | 490-650 | 20 | --- | 34 | --- | --- | d=2a | d=3a | |
| D | 390 | 370 | 350 | 330 | 490-650 | 20 | --- | --- | 34 | --- | d=2a | d=3a | |
| E | 390 | 370 | 350 | 330 | 490-650 | 20 | --- | --- | --- | 27 | d=2a | d=3a | |
| Q420 | A | 420 | 400 | 380 | 360 | 520-680 | 18 | --- | --- | --- | --- | d=2a | d=3a |
| B | 420 | 400 | 380 | 360 | 520-680 | 18 | 34 | --- | --- | --- | d=2a | d=3a | |
| C | 420 | 400 | 380 | 360 | 520-680 | 19 | --- | 34 | --- | --- | d=2a | d=3a | |
| D | 420 | 400 | 380 | 360 | 520-680 | 19 | --- | --- | 34 | --- | d=2a | d=3a | |
| E | 420 | 400 | 380 | 360 | 520-680 | 19 | --- | --- | --- | 27 | d=2a | d=3a | |
| Q460 | C | 460 | 440 | 420 | 400 | 550-720 | 17 | --- | 34 | --- | --- | d=2a | d=3a |
| D | 460 | 440 | 420 | 400 | 550-720 | 17 | --- | --- | 34 | --- | d=2a | d=3a | |
| E | 460 | 440 | 420 | 400 | 550-720 | 17 | --- | --- | --- | 27 | d=2a | d=3a | |
Packaging & Shipping
We cover the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may occur during transportation. Packaging can also be done according to clients’ requirements.
Process of Production
Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration→ Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging
