9M Galvanised Steel Utility Pole 350daN 200daN For 11kv Power Distribution

9M Galvanised Steel Utility Pole 350daN 200daN For 11kv Power Distribution

  • High Light

    metal utility poles


    metal electrical pole


    9M Galvanised Steel Utility Pole

  • Surface Treatment
    Hot Dip Galvanized
  • Material
    Hot Roll Steel Q345B, GR65
  • Height
  • Thickness
  • Powder Coated
    White, Blue, Sliver, Grey Or More
  • Wind Resistance
    160 Km/h
  • Shape
    Round Or Polygonal
  • Place of Origin
  • Brand Name
  • Certification
    ISO 9001
  • Model Number
  • Minimum Order Quantity
  • Price
    $300 - $1000/ Piece
  • Packaging Details
    40HC or OT, wrap by mat or straw mat
  • Delivery Time
    60 workdays
  • Payment Terms
    L/C, T/T
  • Supply Ability
    5000 pieces every month

9M Galvanised Steel Utility Pole 350daN 200daN For 11kv Power Distribution

                                   9M Steel Pole 350daN 200daN ,Metal Power Pole , Hot Dip Galvanization Steel Utility


Product Description

The products above are steel utility poles made specifically for steel pole 300daN ,200daN ,Metal power pole ,

  • Products are designed and manufactured according to ANSI/TIA-222-G structural standards
  • Only our company can comply to these global manufacturing standards which gives us an edge over our competitors
  • Products are hot dip galvanized according to ISO 1461 Stardand.
  • Pole shaft material : Q355
  • Material code : ASTM 572 GR50
  • We possess the ISO 9001:2015 certification and are committed to giving our customers the best products and service
  • We provide additional assistance if required including supervision and supplementary components
  • We accommodate various designs according to our customers’ specifications

To design in accordance with PLS software, we will require the following design parameters:

Product Specifications

Product Name

steel pole 300daN ,200daN ,Metail power pole , Desco Bangladesh market

Suitable Uses

11kv Power Distribution






Q355B/ A572 gr50, Minimum yield strength >= 355n/mm2

Q235B/A36, Minimum yield strength >= 235n/mm2

Other materials may be used as per request (Q460, ASTM573 GR65, GR50, SS400, SS490, to ST52)

Tolerance of Dimensions

+- 1%


10 -15KV

Safety Factor

Safety factor for conducting wire: 2.1

Safety factor for grounding wire: 2.1

Design Load in Kg

300 - 1000 Kg applied to 50cm from pole top


Name plate through rivet or glue, engraving, embossment as per customers' requirement

Surface Treatment

Hot Dip Galvanization according to ASTM A123 standards/Powder Coating

Joint of Poles

Insert Mode, Inner Flange Mode, Face to Face Joint Mode

Design of Poles

Against earthquake of 8 grade

Wind Resistance

120 km/h or 32m/s

Minimum Yield Strength

355 mpa

Min to Max Ultimate Tensile Strength

490 mpa - 620 mpa


ISO 9001

Length per Section

2 Section /1 section


Internal and external double welding process produces a seamless surface

Welding Standard: AWS (American Welding Society) D 1.1




Packaging & Shipping


We cover the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may occur during transportation. Packaging can also be done according to clients’ requirements.


Process of Production

Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding → Hole Drilling → Calibration→ Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging
